OpenLDAP单机搭建手册参考：CentOS上OpenLDAP Server使用cn=config方式配置

配置双主高可用OpenLDAP

  1. 准备两台centos 7服务器，作为两台OpenLDAP Server的运行主机
Server ID 系统版本 IP
1 centos 7 192.168.1.2
2 centos 7 192.168.1.3
  1. 按照CentOS上OpenLDAP Server使用cn=config方式配置的方式在两台主机上部署好OpenLDAP Server。做到第6步即可，即启动openldap server
  2. 在两台主机上启动syncprov模块
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    $ cat syncprov_mod.ldif
    dn: cn=module,cn=config
    objectClass: olcModuleList
    cn: module
    olcModulePath: /usr/lib64/openldap
    olcModuleLoad: syncprov.la
    $ ldapadd -Y EXTERNAL -H ldapi:/// -f syncprov_mod.ldif
    SASL/EXTERNAL authentication started
    SASL username: gidNumber=0+uidNumber=0,cn=peercred,cn=external,cn=auth
    SASL SSF: 0
    adding new entry "cn=module,cn=config"
  3. 启动OpenLDAP主主同步
    在两台机器上创建configrep.ldif文件，并执行配置
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    34
    35
    36
    37
    38
    39
    40
    41
    42
    43
    44
    45
    46
    47
    $ cat configrep.ldif
    ### Update Server ID with LDAP URL ###

    dn: cn=config
    changetype: modify
    replace: olcServerID
    olcServerID: 1 ldap://192.168.1.2
    olcServerID: 2 ldap://192.168.1.3

    ### Enable replication ###

    dn: olcOverlay=syncprov,olcDatabase={2}hdb,cn=config
    changetype: add
    objectClass: olcOverlayConfig
    objectClass: olcSyncProvConfig
    olcOverlay: syncprov

    ### Adding details for replication ###

    dn: olcDatabase={2}hdb,cn=config
    changetype: modify
    add: olcSyncRepl
    olcSyncRepl:
      rid=001
      provider=ldap://192.168.1.2
      binddn="cn=Manager,dc=example,dc=com"
      bindmethod=simple
      credentials=redhat
      searchbase="dc=example,dc=com"
      type=refreshAndPersist
      retry="5 5 300 5"
      timeout=1
    olcSyncRepl:
      rid=002
      provider=ldap://192.168.1.3
      binddn="cn=Manager,dc=example,dc=com"
      bindmethod=simple
      credentials=redhat
      searchbase="dc=example,dc=com"
      type=refreshAndPersist
      retry="5 5 300 5"
      timeout=1
    -
    add: olcMirrorMode
    olcMirrorMode: TRUE

    $ ldapmodify -Y EXTERNAL -H ldapi:/// -f configrep.ldif
  4. 配置ldap启动host，更新/etc/sysconfig/slapd
    1
    2
    $ cat /etc/sysconfig/slapd
    SLAPD_URLS="ldapi:/// ldap://192.168.1.2"
    192.168.1.2、192.168.1.3根据主机ip确定。
  5. 重启slapd
    1
    $ systemctl restart slapd
    至此，dc=example,dc=com 下的内容便可以在两个服务器上同步了。

实践测试

  1. 在ldap1服务器192.168.1.2中创建ldap server的基础结构
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    $ cat base.ldif
    dn: dc=example,dc=com
    objectClass: dcObject
    objectClass: organization
    o: example.com

    dn: ou=users,dc=example,dc=com
    objectClass: organizationalUnit
    objectClass: top
    ou: users

    dn: ou=groups,dc=example,dc=com
    objectClass: organizationalUnit
    objectClass: top
    ou: groups
    $ ldapadd -h 192.168.1.2 -x -D "cn=Manager,dc=example,dc=com" -w redhat -f base.ldif
  2. 检查ldap1和ldap2中的数据对比
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    ## 检查ldap1 192.168.1.2中的数据
    $ ldapsearch -h 192.168.1.2 -x -D 'cn=Manager,dc=example,dc=com' -b dc=example,dc=com -w redhat
    # extended LDIF
    #
    # LDAPv3
    # base <dc=example,dc=com> with scope subtree
    # filter: (objectclass=*) 19L, 623C
    # requesting: ALL
    #

    # example.com
    dn: dc=example,dc=com
    objectClass: dcObject
    objectClass: organization
    o: example.com
    dc: example

    # users, example.com
    dn: ou=users,dc=example,dc=com
    objectClass: organizationalUnit
    ou: users

    # groups, example.com
    dn: ou=groups,dc=example,dc=com
    objectClass: organizationalUnit
    ou: groups

    # search result
    search: 2
    result: 0 Success

    # numResponses: 4
    # numEntries: 3
    与ldap2 192.168.1.3中的数据进行对比
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25
    26
    27
    28
    29
    30
    31
    32
    33
    ## 检查ldap2 192.168.1.3中的数据
    $ ldapsearch -h 192.168.1.3 -x -D 'cn=Manager,dc=example,dc=com' -b dc=example,dc=com -w redhat
    # extended LDIF
    #
    # LDAPv3
    # base <dc=example,dc=com> with scope subtree
    # filter: (objectclass=*) 19L, 623C
    # requesting: ALL
    #

    # example.com
    dn: dc=example,dc=com
    objectClass: dcObject
    objectClass: organization
    o: example.com
    dc: example

    # users, example.com
    dn: ou=users,dc=example,dc=com
    objectClass: organizationalUnit
    ou: users

    # groups, example.com
    dn: ou=groups,dc=example,dc=com
    objectClass: organizationalUnit
    ou: groups

    # search result
    search: 2
    result: 0 Success

    # numResponses: 4
    # numEntries: 3
    数据是一样的，注意：ldap2 192.168.1.3服务器的数据是从192.168.1.2中同步过来的。
  3. 可以对ldap2 192.168.1.3中进行数据更新，再查看ldap1 192.168.1.2中的数据。确认互为主
    在ldap2中添加用户
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
$ cat users.ldif
dn: uid=testuser,ou=users,dc=example,dc=com
uid: testuser
cn: testuser
objectClass: shadowAccount
objectClass: top
objectClass: person
objectClass: inetOrgPerson
objectClass: posixAccount
userPassword: {SSHA}5rMM/3f8Ki13IyarGTtwzieoTu7KMgwc
shadowLastChange: 17016
shadowMin: 0
shadowMax: 99999
shadowWarning: 7
loginShell: /bin/bash
uidNumber: 1000
gidNumber: 1000
homeDirectory: /home/testuser
sn: testuser
mail: testuser@example.com
$ ldapadd  -h 192.168.1.3 -x -D cn=Manager,dc=example,dc=com -f users.ldif -w redhat

参考文章

OpenLDAP 极速搭建：双主同步
